Colormetrics P3000
Integrirano rješenje za savladavanje dnevnih zadataka sa lakoćom. Opremljen ekranom IP64 certifikacije, otporni su na prašinu, tekućinu i prljavštinu. Veliki 17 inčni monitor ističe se zahvaljujući tankom obrubu, a vitko aluminijsko kućište pridaje mu moderan izgled.
System
CPU Intel Celeron J1900 QC 2.0 Ghz
System memory 4 GB SO-DIMM, DDR3L, 1333 MHz, max. 8 GB (1 bank)
Chipset Intel Baytrail platform
Hard disk drive Min. 320 GB HDD, optional SSD
Graphics chip Intel HD graphics
Supported operating systems WS7E, POSReady 7, Windows Embedded 8.1 Industry, Linux
Housing Aluminium
Display
LCD screen size 43.2 cm (17”) LCD
Maximum resolution 1280 x 1024 pixels
Brightness 250 nits, LED
Touch screen 5-wire resistive, PCAP
Interfaces
USB 3x 2.0, 1x 3.0, 1x 24V pUSB
eSATA 1x
Serial/COM 3x DB9, 1x RJ45 (powered)
Parallel Optional
LAN 1x Gigabit
VGA 1x
Cash drawer port 1x (12 V RJ11)
PSU
150 watts (integrated in the stand)
Other
Dimensions (WxDxH) 410 x 385 x 296 mm (with stand)
Operating temperature 0 to 35 ºC
Certification CE, FCC, RoHS
Mount VESA 100 x 100 mm
Options
Customer display 2 x 20 characters (integrated)
Customer-facing screen 20.3 cm (8”) or 38.1 cm (15”) pole
Barcode scanner 1D or 2D barcode scanner
Waiter lock iButton, Addimat
RFID MiFare
Colour Black
UPS Optional
System
CPU Intel Celeron G540 2.5 GHz, Intel G850 2.90 GHz (optional), Intel i3-2120 3.30 GHz (optional)
System memory 4 GB DDR3 RAM (up to 8 GB, 1 Slot)
Chipset Intel H61
Hard disk drive 320 GB HDD, optional SSD
Graphics chip Intel integrated
Supported operating systems Linux, Windows 7, Embedded Standard 7,
PosReady 7, Windows 8
Housing Aluminium
Display
LCD screen size 43.18 cm (17”)
Maximum resolution 1280 x 1024 pixels
Brightness 250 cd/m² (350 cd/m² optional)
Touch screen 5-wire resistive, projected capacitive (optional)
Interfaces
USB 2.0 4x
eSATA / USB 2.0 1x
Serial/COM 2x DB9, 1x RJ45
Parallel Available on demand
LAN 1x RJ45 10/100/1000 Base-T
VGA 1x
PS/2 1x
Cash drawer port 1x RJ11 (12V)
Audio Line-out, mic-in
PSU
150 watts (can be integrated in the stand)
Other
Dimensions (WxHxD) 410 x 385 x 296 mm
Operating temperature 0 to 35 ˚C
Certification CE, FCC, RoHS, IP64-Front
Mount VESA 100 mm
Options
Magnetic stripe reader Choice of MSR (track 1, 2, 3), MSR + iButton reader, MSR + smart card reader +
iButton reader, MSR + smart card reader + fingerprint reader
Customer display VFD, 2 x 20 characters
Customer-facing screen 20.3 cm (8”) or 38.1 cm (15”) screen size
Barcode scanner 1D or 2D barcode scanner (optional RFID capability)
Waiter lock iButton (optional RFID capability)
RFID 13.56 MHz (MIFARE)
Colour Black
